Guardian® Horizontal Lifeline Web Kit (65ft)
The Guardian Horizontal Lifeline Web Kit with is a lightweight horizontal lifeline solution that accommodates up to two workers, and features a unique toolless tensioning mechanism for quick and accurate installation. Simply attach the Web HLL to compatible anchorage connectors (6' cross-arm straps included), take up the slack, and tension using the built-in handle. When the tension indicator shows green, you are ready to work. The Web HLL's advanced integrated shock absorber and 1.5" web lifeline assembly work together to keep deflection to a minimum, lowering overall fall clearance requirements.
Kit Includes
- removable ratchet tensioner
- 65 ft double-braided polyester webbing
- (2) 6 ft cross arm straps
- (2) o-rings
- (2) carabiners
- storage bag
Webbing Material | Double-Braided Polyester |
Tensioner Material | Zinc-Plated Steel |
Cross Arm Straps Material | Double-Braided Polyester and Galvanized Steel |
O-Rings Material | Zinc-Plated Steel |
Capacity | 310 lbs. (each, for two workers) or 420 lbs. (for one worker) |
Minimum Breaking Strength | 5000 lbs. |
Kit Weight | 8 lbs. |
Applicable Standards | OSHA 1926 Subpart M, OSHA 1910 |
Part Number | 04662 |
