Guardian® Horizontal Lifeline Beamguard Stanchion
The Guardian Horizontal Lifeline Beamguard Stanchion can be used in combination with any of Guardian’s rope HLL kits, cable HLL kits, or Absorbinator HLL Systems. Able to accommodate up to two workers between each set of stanchions (maximum stanchion spacing is 60’), the Beamguard has three base size options to allow for installation onto a variety of beam sizes. A Pass-Through Top Accessory is also available to facilitate 100% tie-off when transitioning between spans. Wire rope cable is not included and sold separately.
Material | Powder-Coated Steel |
Weight | 43 lbs (Small) or 47 lbs (Medium) or 50 lbs (Large) |
Flange Fit | 1.25" thick, 4"-13.75" width (Small) or 2.125" thick, 4"-19.75" width (Medium) or 3.375" thick, 4"-31.75" width (Large) |
Capacity | 420 lbs. |
Minimum Breaking Strength | 5000 lbs. |
Applicable Standards | ANSI Z359.1-07, ANSI A10.32-12, OSHA 1926 Subpart M, OSHA 1910 |
Part Number | 04700 (Small) 04701 (Medium) 04702 (Large) |
